| Priding
itself on simplicity and high
quality, TOTAL CHAOS now
introduces the next generation of
bolt�on suspension systems with
the release of the Tacoma 4wd and
Prerunner long travel kit. The
result of our total commitment to
raise the bar in performance
suspensions, we now offer you a
choice to run a single 2.5 or dual
2.5 shock set up off the shelf
with this kit.
This suspension system
features 3.5� extended upper and
lower chromoly tubular arms that
cycle 13� of travel.
The lower arms come
pre-tabbed ready to install dual
shocks and feature an internal rib
to gusset the shock mount.
To eliminate the factory
weak link, the upper arms feature
a 1� uniball that bolts to the
factory spindle with an easy to
install slug adapter, no drilling
required.
8� travel shocks bolt
into the existing factory coil
bucket with a bolt-on upper shock
mount. The upper and lower a-arms
pivot in the factory mounting
locations with urethane bushings.
For the 4wd owners,
modified Tundra axles (not
included) bolt-on and
travel does not have to be limited
to run this set up.
This kit includes all
mounting hardware, D.O.T. brake
lines, quad wrapped adjustable
limit straps, powder coat and
clear coat.
We also offer a dual shock
mount upgrade that bolts to the
coil bucket and welds to the frame
to mount a secondary shock.
|
Parts
List:
-
UPPER
A-ARMS
W/ BUSHINGS, UNIBALLS, AND
CLIPS
-
LOWER
A-ARMS
W/ BUSHINGS AND SHOCK MOUNTS
-
TIE-RODS
EXTENSIONS
-
UNIBALL
SPINDLE ADAPTER SLUGS & RETAINING
CLIPS
-
BRAIDED
STAINLESS BRAKE LINES
D.O.T
APPROVED
-
BOLT
ON UPPER SHOCK MOUNTS
-
HARDWARE
-
ADJUSTABLE
LIMIT STRAPS & MOUNTS
|
|
CALL
970-263-4300 FOR TECHNICAL QUESTIONS & PRICES
|
